75A 600V Blue Powerpole Connector Series – the ultimate solution for your AC/DC connectivity needs. Crafted for exceptional performance, this connector series boasts a range of features that set it apart.
Constructed with precision, the connector housing is expertly crafted from UL94V-0-rated plastic and PC materials, ensuring exceptional durability and safety. The contact terminals are made from high-quality silver-plated copper, guaranteeing optimal conductivity for both high and low frequencies.
Item No :
SDOrder(MOQ) :
1Payment :
TTProduct Origin :
DongguanColor :
BlueShipping Port :
ShenzhenLead Time :
Delivery time according to customer requirements75A 600V Blue Powerpole Connector Series
With its innovative touchpoint interface and advanced cold-press manufacturing process, seamless connectivity is achieved. The single-pole design simplifies installation and usage.
Safety and reliability are paramount. The product features are fire-resistant, flame-retardant, and dust-resistant, making it ideal for demanding environments.
Designed for versatility, this single pole connector UPS charger series finds its applications in various fields such as power supply, outdoor equipment, electric vehicles, energy systems, medical devices, industrial machinery, and military applications.
Parameter:
Product Name | 75A 600V Powerpole Connector Series |
Rated current(Amperes) | 75A |
Rated voltage(Volts) | 600V |
Shell color | blue |
Insulation Resistance | 5000MΩ |
Flammability | UL94 V-0 |
(AWG) Contact Barrel Wire Size(AWG) | 6~12AWG |
Process of production | Precision punching |
Environment temperature | -20℃---125℃ |
Material of terminal | Red copper |
Detailed introduction :
At Guang Dong SED, we push boundaries, offering an extensive array of connector accessories that perfectly complement our exceptional OEM wire harness customization services. Our dedication is unwavering – we provide all-encompassing connector and wire harness solutions to address a diverse range of demands.
Our guiding principles are innovation, quality, and an unwavering commitment to customer satisfaction. We aspire to be more than just a supplier; we want to be your dependable collaborator across diverse sectors. Empowered by a state-of-the-art manufacturing facility and an exceptionally skilled team, we are poised to craft trustworthy and high-performance connectors and wire harnesses that exceed even the most stringent requirements.
FQA:
1.Are you the manufacturer?
Yes, we are a manufacturer, brand SED, with the strength of connector and harness one-stop service.
2.What’s your MOQ?
There is no limit on the quantity of purchase, and the order is shipped
3.Is customization supported?
Support LOGO customization, support color customization, support connector open mold injection molding customization, support OEM wiring harness customization.
4.What is the delivery time?
Do not specify the time, order delivery, according to the customer's specified time delivery
5.How to place an order or know more about the products?
Contact sales staff online or by email
