Unipolar connector

/45A 600V Black Electric vehicle connector
45A 600V Black Single-Pole Battery Connectors
45A 600V Black Electric vehicle connector
45A 600V Black Single Pole Lithium battery charging plug
45A 600V Black Single Pole Connector UPS Charger
45A 600V Black Single Pole Tourist car plug

45A 600V Black Electric vehicle connector

Robust high current performance: This black new energy lithium battery plug  boasts an impressive 45A 600V capacity, making it the perfect match for high-power applications such as lithium batteries, charging stations, circuit boards, and more.



 Vibrant Casing Options: Choose from a spectrum of vibrant casing colors including red, black, blue, yellow, green, grey, white, and brown. Elevate your product aesthetics and make a statement with a color that resonates.



  • Item No :

    SD
  • Order(MOQ) :

    1
  • Payment :

    TT
  • Product Origin :

    Dongguan
  • Color :

    Black
  • Shipping Port :

    Shenzhen
  • Lead Time :

    Delivery time according to customer requirements

45A 600V Black New energy lithium battery plug  <



Uniform Gender and Color Matching: No more compatibility concerns. With uniform color-coded connectors, plugging in is a breeze, saving you time and effort.



Multi-Pole Compatibility: Seamlessly create multi-pole configurations, adding a new dimension of versatility to your industrial setups. Whether it's efficient power distribution or flexible connectivity, we've got you covered.



Whether you're seeking efficient power discharge or intricate power connections, the "45A 600V Black Electric Vehicle Connector" is your ultimate choice. Opt for us and experience safer, more stable, and effortlessly streamlined power connections!



Parameter:

Product Name 45A 600V Black Electric Vehicle Connector
Rated current(Amperes)  45A
Rated voltage(Volts) 600V
Shell color Black
Insulation Resistance 9900MΩ
Flammability UL94 V-0
(AWG) Contact Barrel Wire Size(AWG) 10~18AWG
Process of production Precision punching
Environment temperature -20℃---75℃
Material of terminal  Red copper



Detailed introduction :



At Guang Dong SED,  is a modern electronic components comprehensive support enterprise that integrates research and development, manufacturing, sales, and brand representation. Situated in the convenient transport hub of Chashan Town, Dongguan City, Guangdong Province.



Our company specializes in the production and sale of various high-current connectors, plug-in connectors, UPS/EPS power sockets, and more. We cater specifically to manufacturers in the automotive, electric vehicle, communication power, medical equipment, power distribution equipment, material handling equipment, solar energy, and new energy sectors. With our own production and research base, we hold ISO9001 quality system certification. Our products are certified with CE, 3C, and meet environmental requirements such as ROSH and REACH.



FQA:

1.Are you the manufacturer?

Yes, we are a manufacturer, brand SED, with the strength of connector and harness one-stop service.

2.What’s your MOQ?

There is no limit on the quantity of purchase, and the order is shipped

3.Is customization supported?

Support LOGO customization, support color customization, support connector open mold injection molding customization, support OEM wiring harness customization.

4.What is the delivery time?

Do not specify the time, order delivery, according to the customer's specified time delivery

5.How to place an order or know more about the products?

Contact sales staff online or by email

leave a message
If you are interested in our products and want to know more details,please leave a message here,we will reply you as soon as we can.
